500mA三端正電壓調節器 DIODES AZ70M05 AZ70M06 AZ70M08 AZ70M09 AZ70M12
- 品牌：???DIODES
- 型號：???AZ70M05 AZ70M06 AZ70M08 AZ70M09 AZ70M12
General Description
The AZ78MXX series are monolithic integrated circuits designed as fixed-voltage regulators for a wide variety of applications including local, on-card regulation.
This series of regulators are complete with internalcurrent limiting, thermal shutdown protection, and safe-area compensation which make them virtually immune from output overload. If adequate heat sinking are provided, these regulators can deliver output currents up to 0.5A.
The AZ78MXX series are available in two standard plastic packages: TO-220 and TO-252.
Features
· Output Current up to 0.5A
· Fixed Output Voltages of 5V, 6V, 8V, 9V and 12V
· Output Voltage Tolerances of ± 5% over the Full Temperature Range
· Internal Short Circuit Current-Limiting
· Internal Thermal Overload Protection
Applications
· Consumer Electronics
· Microprocessor Power Supply
· Mother Board I/O Power Supply
我司是DIODES正式授權代理商，可以提供技術支持，需要技術資料與樣品可以向我司業務人員索取（13923795851孫生-微信同號）
